Splitting

Mechanica supports modeling processes associated with a particle dividing into two particles, called splitting. In the simplest case, a particle can spawn a new particle in a mass- and volume-preserving split operation under the assumption that the spawned (child) and spawning (parent) particles are identical. During particle splitting, the parent and child particles are randomly placed exactly in contact at the initial position of the parent particle, and both have the same velocity as the parent before the split. The split operation on a particle occurs when calling the Particle method split, which returns the child particle.

import mechanica as mx
class SplittingType(mx.ParticleType):
    pass

splitting_type = SplittingType.get()
parent_particle = splitting_type()
child_particle = parent_particle.split()

Splitting Clusters

Clusters introduce details of morphology and constituent particles to the process of splitting. Mechanica provides support for specifying a number of details concerning how, where and when a cluster divides. The split operation on a cluster also occurs when calling split, though the corresponding cluster method supports a variable number of arguments that define the details of the split. In general, cluster splitting occurs according to a cleavage plane that intersects the cluster, where the constituent particles of the parent cluster before the split are allocated to the parent and child clusters on either side of the intersecting plane.

In the simplest case, a cluster can be divided by randomly selecting a cleavage plane at the center of mass of the cluster. Such a case is implemented by calling split without arguments, as with a particle,

class MyClusterType(mx.ClusterType):
    types = [splitting_type]

my_cluster_type = MyClusterType.get()
my_cluster = my_cluster_type()
my_cluster_d1 = my_cluster.split()

split accepts optional keyword arguments normal and point to define a cleavage plane. If only a normal vector is given, split uses the center of mass of the cluster as the point. For example, to split a cluster along the x axis,

my_cluster_d2 = my_cluster.split(normal=[1., 0., 0.])

or to specify the full normal/point form,

my_cluster_d3 = my_cluster.split(normal=[x, y, z], point=[px, py, pz])

split also supports splitting a cluster along an axis at the center of mass of the cluster, where a random cleavage plane is generated that contains the axis. This case can be implemented by using the optional keyword argument axis.

my_cluster_d4 = my_cluster.split(axis=[x, y, z])

split can also split the cluster by randomly selecting half of the particles in a cluster and assigning them to a child cluster by using the random argument,

my_cluster_d5 = my_cluster.split(random=True)
